煤尘云对瓦斯爆炸6种中间产物相对辐射强度的影响

Influence of coal dust cloud on relative radiation intensity of six intermediates in gas explosion

  • 摘要: 煤矿井下瓦斯煤尘共存爆炸是典型的气固两相化学反应。为了突出了解含煤尘瓦斯爆炸过程中反应中间产物的发展规律,采用瞬态火焰传播实验系统从微观火焰光谱探测角度进行含煤尘瓦斯爆炸现象研究,揭示煤尘云加入后对瓦斯爆炸中间产物光谱特性的影响。体积分数为7%、8%、9%、10%、11%瓦斯分别与130 g/m3煤尘质量浓度的长焰煤、焦煤、无烟煤煤尘云形成混合体系,分析混合体系爆炸过程中关键中间产物的相对辐射强度。实验结果表明,130 g/m3煤尘质量浓度的长焰煤/焦煤/无烟煤煤尘云与不同体积分数瓦斯形成的混合体系爆炸,与瓦斯中间产物辐射强度峰值相比,中间产物辐射强度增强,下部光纤峰值增强幅值比上部光纤的峰值增幅幅度大,6种反应中间产物相对辐射强度峰值由大到小排序为C2·>O·>CH2O>CH·>O2>CHO·。煤种变质程度对中间产物相对辐射强度峰值影响幅度从大到小排序为:长焰煤>焦煤>无烟煤煤尘云。煤尘云参与瓦斯爆炸,增强了瓦斯爆炸体系6种中间产物的相对辐射强度,煤尘云对低浓度瓦斯爆炸中间产物相对辐射强度峰值的影响比高浓度瓦斯强烈,不同变质程度煤尘云对CH2O、O·、C2·的累积速率影响作用大于CHO·、O2。可以在后期研发针对瓦斯爆炸的新型抑爆剂时,综合考虑将CH2O、O·、C2·三种反应中间产物作为靶向抑制目标之一,提升新型抑爆剂的抑爆效率。



    Abstract: The gas and coal dust hybrid explosion in coal mines is a typical gas-solid two-phase chemical reaction. To highlight the development law of reaction intermediates in the process of explosion of gas containing coal dust, using the transient flame propagation experimental system, the phenomenon of explosion of gas containing coal dust was studied from the perspective of microscopic flame spectrum detection, and the influence of coal dust cloud addition on the spectral characteristics of gas explosion intermediates was revealed. Spectrometer was used to capture the emission spectral signal radiation intensity of the key intermediates generated in the mixed system explosion of 7%,8%,9%,10%,11% gas concentration and long-flame coal, charred coal, anthracite coal dust cloud at the concentration of 130 g/m3 coal dust. The results show that in the mixed system formed by the same concentration 130 g/m3 of long-flame coal/charred coal/anthracite coal dust cloud and different concentrations of gas explodes, compared with the radiation intensity peak of intermediates of pure gas, the radiation intensity is enhanced, and the enhancement amplitude of the lower fiber peak is larger than that of the upper fiber peak, the relative radiation intensity peaks of the six reaction intermediates are in the order of C2·>O·>CH2O>CH·>O2>CHO·. The influence of the degree of coal metamorphism on the peak relative radiation intensity of intermediate products is ranked from large to small: long-flame coal > charred coal > anthracite coal dust cloud. The coal dust cloud participates in the gas explosion, which enhances the concentration of the six intermediates in the gas explosion system. The coal dust cloud has a stronger influence on the relative radiation intensity peak of the low-concentration gas explosion intermediates than the high-concentration gas. The cumulative rates of CH2O,O·,and C2· are more affected by coal dust clouds with different metamorphic degrees than CHO·,and O2. When researching and developing new detonation suppressors for gas explosions in the later stage, the three reaction intermediates of CH2O/O·/C2· can be comprehensively considered as one of the targeted inhibition targets, to improve the detonation suppression efficiency of new detonation inhibitor.



/
